8 × 10/100/1000BASE-T Gigabit Ethernet PoE+ ports (128W PoE budget) for powering and connecting network devices
4 × 2.5GE SFP uplink ports for high-speed fiber connectivity and enhanced bandwidth performance
Built-in AC power supply for stable and reliable operation
Fanless design for silent operation and improved durability
Managed Layer 2 switch designed for efficient and flexible network control
Ideal for IP cameras, wireless access points, VoIP phones, and SMB enterprise networks
Supports high-speed data transmission with improved uplink capacity for modern network demands

Managed Layer 2 switch with web-based management for easy configuration and monitoring
8 × RJ-45 Gigabit Ethernet ports for reliable high-speed connectivity
Quality of Service (QoS) support for traffic prioritization and smooth network performance
Access Control List (ACL) for enhanced network security and access control
MAC address table supporting up to 16,000 entries for efficient device handling
Switching capacity of 26 Gbit/s for stable and high-performance data transmission
1U rack-mountable design for standard network cabinet installation
AC power supply included for ready-to-use deployment in enterprise and SMB environments

The Huawei S220-8P4S is an 8-port Gigabit Layer 2 managed PoE+ switch designed for reliable and efficient network performance in SMB, SOHO, and edge-office environments. It features 8 × Gigabit Ethernet PoE+ ports and 4 × GE SFP uplink ports for flexible fiber connectivity and network expansion.

With a 125W PoE power budget, it efficiently supports devices such as IP cameras, wireless access points, and VoIP phones. The switch delivers a 24 Gbps switching capacity and 18 Mpps forwarding rate for smooth and stable data transmission.

It supports up to 4094 VLANs along with advanced Layer 2 protocols including STP, RSTP, MSTP, and ERPS for enhanced network stability and redundancy. Security features, QoS, and ACL functions ensure controlled and prioritized traffic handling.

Flexible management options via Web, CLI, App, SNMP, and SSH make it easy to deploy and maintain, making it a strong choice for scalable and secure network infrastructure.

HUAWEI eKitEngine S210I-8P4SX is an industrial-grade managed Layer 2 Ethernet switch designed for reliable performance in harsh and outdoor environments. It features 8 × Gigabit PoE+ RJ45 ports, 2 × GE SFP fiber ports, and 2 × 10GE SFP+ uplink ports for high-speed and flexible network connectivity.

Built for demanding deployments, it supports PoE+ power delivery for IP devices such as cameras and access points while ensuring stable data transmission. The switch offers fanless cooling for silent operation and enhanced durability, along with wide temperature support for industrial use cases.

It also provides flexible management options, including cloud and local management, making it suitable for smart surveillance, industrial networks, and enterprise edge applications requiring high reliability and scalability.

24 × 10/100/1000BASE-T Gigabit Ethernet ports for high-speed wired connectivity
2 × GE SFP uplink ports for flexible fiber and long-distance network expansion
PoE+ support for powering IP cameras, access points, and VoIP devices
AC powered, ensuring stable and reliable operation
Unmanaged plug-and-play design with no configuration required
19-inch rack-mountable assembly for standard network cabinet installation
Ideal for SMB networks, surveillance systems, and office connectivity solutions.

16 × 10/100/1000BASE-T Gigabit Ethernet ports for high-speed wired connectivity
2 × GE SFP uplink ports for flexible fiber or long-distance network expansion
Unmanaged plug-and-play switch with no configuration required
Built-in AC power supply for simple and reliable deployment
Fanless, silent design with natural heat dissipation for noise-free operation
Enterprise-grade Layer 2 switching performance for stable data transmission
Ideal for office networks, IP surveillance systems, access points, and SMB environments
Compact rack-mountable design suitable for flexible installation scenarios

8 × Gigabit Ethernet (RJ45) ports for high-speed LAN connectivity
2 × Gigabit SFP uplink ports for fiber expansion
Unmanaged plug-and-play design—no configuration required
Fanless, silent, and energy-efficient operation
Compact metal housing for durability and heat dissipation
Supports auto-negotiation, flow control & loop detection
Ideal for SMB networks, surveillance, and office connectivity

8 × 10/100/1000 Mbps Ethernet ports with PoE support
2 × SFP uplink ports for long-distance fiber connectivity
Plug-and-play unmanaged switch—no configuration required
Intelligent PoE power allocation for safe, stable operation
Silent, fanless design and durable metal casing
Ideal for IP cameras, APs, VoIP phones, and SMB networks
Reliable Huawei enterprise-grade performance and protection

Port type: 10M/100M/GE electrical port, SFP optical port
LED indicator: Indicate the power-on, startup, running, alarm, and fault states of the system
Power input: PoE power supply: in compliance with IEEE 802.3at/af
Maximum power consumption: 17.7 W
Operating temperature: –40°C to +65°C (From 1800 m to 5000 m, the maximum operating temperature of the device decreases by 1°C for every 300 m increase in altitude.)
Storage temperature: –40°C to +85°C
Operating humidity: 0%–100% IP rating: IP68
Altitude: –60 m to +5000 m
Atmospheric pressure: 53 kPa to 106 kPa
Antenna type: Built-in directional antennas
Antenna gain: 2.4 GHz: 10 dBi, 5 GHz: 11 dBi, BLE: 5 dBi
Maximum quantity of SSIDs on each radio: ≤ 16
Maximum number of STAs: ≤ 1024 (512/radio)
Maximum transmit power: 2.4 GHz: 28 dBm (combined power), 5 GHz: 27 dBm (combined power)
Power adjustment increment: 1 dBm
Maximum number of nonoverlapping channels: 2.4 GHz (2.412 GHz to 2.472 GHz), 802.11b/g , 20 MHz: 3 , 802.11n , 20 MHz: 3 , 40 MHz: 1 , 802.11ax , 20 MHz: 3 , 40 MHz: 1 , 5 GHz (5.18 GHz to 5.825 GHz) , 802.11a , 20 MHz: 13 , 802.11n , 20 MHz: 13

Settled AP
Wi-Fi 7
7.89 Gbps device rate
Tri-radio
180 access users recommended
Maximum 1,024 access users
26 dBm transmit power
Smart antenna
Optimal coverage range: 30 m

Huawei eKitEngine AP661 is an indoor AP in compliance with Wi-Fi 6 (802.11ax). It can simultaneously provide services on 2.4 GHz (2x2 MIMO), 5 GHz (2x2 MIMO) and 5 GHz (4x4 MIMO) frequency bands, achieving a device rate of up to 6.575 Gbps. Built-in smart antennas of the AP enable always-on Wi-Fi signals for users, significantly enhancing users wireless experiences. These strengths make it ideal for densely populated scenarios such as mobile office, education, and stadiums.
Built-in smart antennas that automatically adjust the coverage direction and signal strength based on the intelligent switchover algorithm to adapt to changes in the external environment, in addition to providing accurate and stable coverage as stations (STAs) move
USB port for IoT expansion (such as ZigBee and RFID)
Working modes: Fit, Fat, and cloud management

Huawei eKitEngine AP265E is an indoor slim wall plate access point (AP) in compliance with the Wi-Fi 6 (802.11ax) standard. It can simultaneously provide services on the 2.4 GHz (2x2 MIMO) and 5 GHz (2x2 MIMO) frequency bands with four spatial streams, delivering a data rate of up to 2.975 Gbps.
The AP provides one GE uplink port and four GE downlink ports. It can be installed on a desk, wall, ceiling, or junction box, meeting connection requirements in multiple scenarios. The AP is small and easy to deploy, ideal for indoor coverage scenarios such as budget hotels, hospitals, commercial stores, and schools.

Port Uplink: 1 x 10M/100M/GE electrical port
LED indicator: Indicate the power-on, startup, running, alarm, and fault states of the system.
Power input: PoE power supply: in compliance with IEEE 802.3at
Maximum power consumption: 9.4 W (excluding PoE OUT)
Operating temperature: 0°C to 40°C (From 1800 m to 5000 m, the maximum temperature of the device decreases by 1°C for every 300 m increase in altitude.)
Storage temperature: –40°C to +70°C
Operating humidity: 5% to 95% (non-condensing)
Altitude: –60 m to +5000 m
Atmospheric pressure: 53 kPa to 106 kPa
Antenna type: Built-in smart antennas
Antenna gain: 2.4 GHz: 4 dBi, 5 GHz: 4 dBi
Maximum quantity of SSIDs: 16
Maximum number of access STAs: 128
Maximum transmit power: 2.4 GHz: 23 dBm (combined power), 5 GHz: 23 dBm (combined power)
Power adjustment increment: 1 dBm

Huawei eKitEngine AP361 is an indoor Wi-Fi 6 (802.11ax) AP. It can simultaneously provide services on the 2.4 GHz (2x2) and 5 GHz (2x2) frequency bands. This AP features high bandwidth, high concurrency, and compact size, facilitating flexible deployment and saving customer investment. Such strengths make the AP a good fit for indoor coverage in SME markets, such as SOHO enterprise offices, small- and medium-sized hospitals, commercial real estate, budget chain hotels, and primary and secondary schools.
