Port type: 10M/100M/GE electrical port, SFP optical port
LED indicator: Indicate the power-on, startup, running, alarm, and fault states of the system
Power input: PoE power supply: in compliance with IEEE 802.3at/af
Maximum power consumption: 17.7 W
Operating temperature: –40°C to +65°C (From 1800 m to 5000 m, the maximum operating temperature of the device decreases by 1°C for every 300 m increase in altitude.)
Storage temperature: –40°C to +85°C
Operating humidity: 0%–100% IP rating: IP68
Altitude: –60 m to +5000 m
Atmospheric pressure: 53 kPa to 106 kPa
Antenna type: Built-in directional antennas
Antenna gain: 2.4 GHz: 10 dBi, 5 GHz: 11 dBi, BLE: 5 dBi
Maximum quantity of SSIDs on each radio: ≤ 16
Maximum number of STAs: ≤ 1024 (512/radio)
Maximum transmit power: 2.4 GHz: 28 dBm (combined power), 5 GHz: 27 dBm (combined power)
Power adjustment increment: 1 dBm
Maximum number of nonoverlapping channels: 2.4 GHz (2.412 GHz to 2.472 GHz), 802.11b/g , 20 MHz: 3 , 802.11n , 20 MHz: 3 , 40 MHz: 1 , 802.11ax , 20 MHz: 3 , 40 MHz: 1 , 5 GHz (5.18 GHz to 5.825 GHz) , 802.11a , 20 MHz: 13 , 802.11n , 20 MHz: 13

Settled AP
Wi-Fi 7
7.89 Gbps device rate
Tri-radio
180 access users recommended
Maximum 1,024 access users
26 dBm transmit power
Smart antenna
Optimal coverage range: 30 m

Huawei eKitEngine AP661 is an indoor AP in compliance with Wi-Fi 6 (802.11ax). It can simultaneously provide services on 2.4 GHz (2x2 MIMO), 5 GHz (2x2 MIMO) and 5 GHz (4x4 MIMO) frequency bands, achieving a device rate of up to 6.575 Gbps. Built-in smart antennas of the AP enable always-on Wi-Fi signals for users, significantly enhancing users wireless experiences. These strengths make it ideal for densely populated scenarios such as mobile office, education, and stadiums.
Built-in smart antennas that automatically adjust the coverage direction and signal strength based on the intelligent switchover algorithm to adapt to changes in the external environment, in addition to providing accurate and stable coverage as stations (STAs) move
USB port for IoT expansion (such as ZigBee and RFID)
Working modes: Fit, Fat, and cloud management

Huawei eKitEngine AP265E is an indoor slim wall plate access point (AP) in compliance with the Wi-Fi 6 (802.11ax) standard. It can simultaneously provide services on the 2.4 GHz (2x2 MIMO) and 5 GHz (2x2 MIMO) frequency bands with four spatial streams, delivering a data rate of up to 2.975 Gbps.
The AP provides one GE uplink port and four GE downlink ports. It can be installed on a desk, wall, ceiling, or junction box, meeting connection requirements in multiple scenarios. The AP is small and easy to deploy, ideal for indoor coverage scenarios such as budget hotels, hospitals, commercial stores, and schools.

Port Uplink: 1 x 10M/100M/GE electrical port
LED indicator: Indicate the power-on, startup, running, alarm, and fault states of the system.
Power input: PoE power supply: in compliance with IEEE 802.3at
Maximum power consumption: 9.4 W (excluding PoE OUT)
Operating temperature: 0°C to 40°C (From 1800 m to 5000 m, the maximum temperature of the device decreases by 1°C for every 300 m increase in altitude.)
Storage temperature: –40°C to +70°C
Operating humidity: 5% to 95% (non-condensing)
Altitude: –60 m to +5000 m
Atmospheric pressure: 53 kPa to 106 kPa
Antenna type: Built-in smart antennas
Antenna gain: 2.4 GHz: 4 dBi, 5 GHz: 4 dBi
Maximum quantity of SSIDs: 16
Maximum number of access STAs: 128
Maximum transmit power: 2.4 GHz: 23 dBm (combined power), 5 GHz: 23 dBm (combined power)
Power adjustment increment: 1 dBm

Huawei eKitEngine AP361 is an indoor Wi-Fi 6 (802.11ax) AP. It can simultaneously provide services on the 2.4 GHz (2x2) and 5 GHz (2x2) frequency bands. This AP features high bandwidth, high concurrency, and compact size, facilitating flexible deployment and saving customer investment. Such strengths make the AP a good fit for indoor coverage in SME markets, such as SOHO enterprise offices, small- and medium-sized hospitals, commercial real estate, budget chain hotels, and primary and secondary schools.
