Wi-Fi standard 2.4 GHz: 802.11b/g/n/ax/be 5 GHz:802.11a/n/ac/ac Wave 2/ax/be
Installation Type Wall,Pole
Optimal Signal Distance (m) 250
Max Number of Access Users 1024
Recommended Number of Access Users 130
Device Rate 6.45 Gbps
Maximum number of physical ports on the entire device 2.5GE (RJ45) x 1, 100M/1000M/2500M auto-sensing 10GE optical (SFP+), GE/2.5GE/10GE auto-sensing
Radio number 2
Maximum channel bandwidth [MHz] Radio 0 (2.4 GHz): 40 MHz Radio 1 (5 GHz): 160 MHz
Maximum transmit power 2.4 GHz: 25 dBm/chain 28 dBm (combined power) 5 GHz: 24 dBm/chain 30 dBm (combined power)
MIMO spatial streams Radio 0 (2.4 GHz): 2×2 Radio 1 (5 GHz): 4×4
Maximum power consumption [W] 20.4 (excluding USB)
Input voltage range [V] DC: 43.2 V to 57.6 V PoE: 802.3bt/at/af
Dimensions without packaging (H x W x D) [mm(in.)] 220 mm x 250 mm x 77 mm (8.66 in. x 9.84 in. x 3.03 in.)
Dimensions with packaging (H x W x D) [mm(in.)] 170 mm x 555 mm x 370 mm (6.69 in. x 21.85 in. x 14.57 in.)
Weight without packaging [kg(lb)] 2.76 kg (6.08 lb)
Weight with packaging [kg(lb)] 5.65 kg (12.46 lb)
Long-term operating temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F) (From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.], the maximum temperature of the device decreases by 1°C [1.8°F] for every 300 m [984.25 ft.] increase in altitude.)
Long-term operating relative humidity [RH] Operating humidity: 0% RH to 100% RH Storage humidity: 5% RH to 95% RH (non-condensing)
Radio interface Built-in directional antennas
Antenna gain 2.4 GHz: 10 dBi/chain (peak value) 10 dBi (combined gain) 5 GHz: 11 dBi/chain (peak value) 10 dBi (combined gain)
Operating frequency band 2.4GHz,5GHz
Ingress protection level (dustproof/waterproof) IP68
Beamwidth of the built-in antenna [degrees] 2.4 GHz: – Horizontal plane: 70° – Vertical plane: 35° 5 GHz: – Horizontal plane: 60° – Vertical plane: 20°
